Projetando uma Arquitetura de Scraping Confiavel

Além dos scripts: Por que a arquitetura importa

Um raspador de arquivo único funciona bem por cem páginas. Mas quando você precisa coletar milhões de pontos de dados em dezenas de sites alvo em um cronograma recorrente, você precisa de um sistema — não de um script. Uma arquitetura de raspagem confiável separa preocupações em componentes independentes que podem ser escalados, monitorados e recuperados de forma independente.

Este guia percorre o design de um sistema de raspagem de produção, desde o agendamento de URLs até o gerenciamento de proxy até o armazenamento de dados. Cada componente é ilustrado com código e conectado ao Infra- estrutura proxyHat.

Um raspador bem arquitetado trata a coleta de dados como um problema de engenharia, não um problema de hacking. Cada componente tem uma única responsabilidade, interfaces claras e comportamento observável.

Visão Geral da Arquitetura do Sistema

Um sistema de raspagem de produção consiste em seis componentes principais:

┌─────────────┐     ┌──────────────┐     ┌─────────────────┐
│  Scheduler   │────▶│  URL Queue   │────▶│  Crawler Pool   │
│  (cron/API)  │     │  (Redis)     │     │  (workers)      │
└─────────────┘     └──────────────┘     └────────┬────────┘
                                                   │
                                          ┌────────▼────────┐
                                          │  Proxy Layer     │
                                          │  (ProxyHat)      │
                                          └────────┬────────┘
                                                   │
                                          ┌────────▼────────┐
                                          │  Parser          │
                                          │  (extract data)  │
                                          └────────┬────────┘
                                                   │
                    ┌──────────────┐      ┌────────▼────────┐
                    │  Monitoring  │◀─────│  Storage         │
                    │  (metrics)   │      │  (DB / files)    │
                    └──────────────┘      └─────────────────┘

Componente 1: Scheduler

O agendador decide quais URLs rastejar e quando. Ele gerencia frequência de rastreamento, níveis de prioridade, e garante que nenhuma URL é raspada mais frequentemente do que o necessário.

import redis
import json
import time
from datetime import datetime, timedelta
class CrawlScheduler:
    """Manages crawl schedules and feeds URLs to the queue."""
    def __init__(self, redis_url: str = "redis://localhost:6379"):
        self.redis = redis.from_url(redis_url)
        self.queue_key = "scraper:url_queue"
        self.schedule_key = "scraper:schedules"
        self.seen_key = "scraper:seen_urls"
    def add_schedule(self, name: str, urls: list[str], interval_hours: int, priority: int = 5):
        """Register a recurring crawl job."""
        self.redis.hset(self.schedule_key, name, json.dumps({
            "urls": urls,
            "interval_hours": interval_hours,
            "priority": priority,
            "last_run": None,
        }))
    def tick(self):
        """Check all schedules and enqueue URLs that are due."""
        schedules = self.redis.hgetall(self.schedule_key)
        enqueued = 0
        for name, data in schedules.items():
            schedule = json.loads(data)
            last_run = schedule.get("last_run")
            interval = timedelta(hours=schedule["interval_hours"])
            if last_run and datetime.fromisoformat(last_run) + interval > datetime.utcnow():
                continue
            for url in schedule["urls"]:
                self.enqueue(url, priority=schedule["priority"])
                enqueued += 1
            schedule["last_run"] = datetime.utcnow().isoformat()
            self.redis.hset(self.schedule_key, name, json.dumps(schedule))
        return enqueued
    def enqueue(self, url: str, priority: int = 5):
        """Add a URL to the crawl queue with deduplication."""
        # Skip if recently seen (within 1 hour)
        if self.redis.sismember(self.seen_key, url):
            return False
        self.redis.zadd(self.queue_key, {
            json.dumps({"url": url, "enqueued_at": time.time()}): priority
        })
        self.redis.sadd(self.seen_key, url)
        self.redis.expire(self.seen_key, 3600)  # 1-hour dedup window
        return True
    def dequeue(self, batch_size: int = 10) -> list[dict]:
        """Pull the highest-priority URLs from the queue."""
        items = self.redis.zpopmax(self.queue_key, batch_size)
        return [json.loads(item) for item, score in items]
    @property
    def queue_size(self) -> int:
        return self.redis.zcard(self.queue_key)
# Usage
scheduler = CrawlScheduler()
scheduler.add_schedule(
    name="product_prices",
    urls=[f"https://example.com/product/{i}" for i in range(1, 1001)],
    interval_hours=6,
    priority=8,
)
scheduler.add_schedule(
    name="competitor_pages",
    urls=["https://competitor.com/pricing", "https://competitor.com/features"],
    interval_hours=24,
    priority=5,
)
# Run every minute via cron
enqueued = scheduler.tick()
print(f"Enqueued {enqueued} URLs, queue size: {scheduler.queue_size}")

Componente 2: Fila de URL

A fila separa o agendamento do rastreamento. Ele fornece ordenação de prioridade, contrapressão e persistência — então nenhum URL é perdido se um rastreador falhar.

// Node.js queue with Bull
const Queue = require('bull');
const crawlQueue = new Queue('crawl', 'redis://localhost:6379', {
  defaultJobOptions: {
    attempts: 3,
    backoff: { type: 'exponential', delay: 2000 },
    removeOnComplete: 100,
    removeOnFail: 500,
  },
});
// Add URLs with priority (lower number = higher priority)
async function enqueueUrls(urls, priority = 5) {
  const jobs = urls.map(url =>
    crawlQueue.add(
      { url, enqueuedAt: Date.now() },
      { priority, jobId: url } // jobId for deduplication
    )
  );
  await Promise.all(jobs);
  console.log(`Enqueued ${urls.length} URLs`);
}
// Worker processes URLs
crawlQueue.process(10, async (job) => {
  const { url } = job.data;
  // Crawl logic here (see Crawler Pool below)
  return { url, status: 'completed' };
});
crawlQueue.on('failed', (job, err) => {
  console.error(`Job ${job.id} failed: ${err.message}`);
});

Componente 3: Grupo de arrasto

O pool de rastreamento busca páginas simultaneamente através do camada de middleware proxy. Gerencia limites de concorrência, lida com repetições, e passa respostas brutas para o analisador.

import asyncio
import aiohttp
import uuid
import time
from typing import Optional
class CrawlerPool:
    """Concurrent crawler with proxy rotation and retry logic."""
    def __init__(
        self,
        concurrency: int = 30,
        max_retries: int = 3,
        timeout: int = 30,
    ):
        self.concurrency = concurrency
        self.max_retries = max_retries
        self.timeout = aiohttp.ClientTimeout(total=timeout)
        self.semaphore = asyncio.Semaphore(concurrency)
        self.stats = {"success": 0, "failed": 0, "retries": 0}
    def _get_proxy(self, country: Optional[str] = None) -> str:
        session_id = uuid.uuid4().hex[:8]
        username = f"USERNAME-session-{session_id}"
        if country:
            username += f"-country-{country}"
        return f"http://{username}:PASSWORD@gate.proxyhat.com:8080"
    async def fetch(
        self,
        session: aiohttp.ClientSession,
        url: str,
        country: Optional[str] = None,
    ) -> dict:
        async with self.semaphore:
            for attempt in range(self.max_retries + 1):
                proxy = self._get_proxy(country)
                start = time.time()
                try:
                    async with session.get(
                        url, proxy=proxy, timeout=self.timeout,
                        headers={
                            "User-Agent": "Mozilla/5.0 (Windows NT 10.0; Win64; x64) "
                                          "AppleWebKit/537.36 Chrome/131.0.0.0 Safari/537.36",
                            "Accept": "text/html,application/xhtml+xml,*/*;q=0.8",
                        },
                    ) as response:
                        body = await response.text()
                        latency = time.time() - start
                        if response.status in (403, 429, 503) and attempt < self.max_retries:
                            self.stats["retries"] += 1
                            await asyncio.sleep(2 ** attempt)
                            continue
                        if response.status < 400:
                            self.stats["success"] += 1
                        else:
                            self.stats["failed"] += 1
                        return {
                            "url": url,
                            "status": response.status,
                            "body": body,
                            "latency": latency,
                            "success": response.status < 400,
                        }
                except Exception as e:
                    if attempt < self.max_retries:
                        self.stats["retries"] += 1
                        await asyncio.sleep(2 ** attempt)
                        continue
                    self.stats["failed"] += 1
                    return {
                        "url": url,
                        "error": str(e),
                        "latency": time.time() - start,
                        "success": False,
                    }
    async def crawl(self, urls: list[str], country: Optional[str] = None) -> list[dict]:
        async with aiohttp.ClientSession() as session:
            tasks = [self.fetch(session, url, country) for url in urls]
            return await asyncio.gather(*tasks)
# Usage
crawler = CrawlerPool(concurrency=30, max_retries=3)
urls = [f"https://example.com/product/{i}" for i in range(500)]
results = asyncio.run(crawler.crawl(urls, country="us"))
print(f"Success: {crawler.stats['success']}, Failed: {crawler.stats['failed']}")

Componente 4: Analisador

O analisador transforma HTML bruto em dados estruturados. Mantenha a lógica de análise separada do rastreamento — isso o torna testável, reutilizável e fácil de atualizar quando os sites de destino mudam.

from dataclasses import dataclass
from typing import Optional
from bs4 import BeautifulSoup
import json
@dataclass
class ProductData:
    url: str
    title: Optional[str] = None
    price: Optional[float] = None
    currency: Optional[str] = None
    availability: Optional[str] = None
    rating: Optional[float] = None
    review_count: Optional[int] = None
    parsed_at: Optional[str] = None
class ProductParser:
    """Extracts structured product data from HTML."""
    def parse(self, url: str, html: str) -> ProductData:
        soup = BeautifulSoup(html, "html.parser")
        data = ProductData(url=url)
        try:
            data.title = self._extract_text(soup, "h1.product-title")
            data.price = self._extract_price(soup)
            data.currency = self._extract_currency(soup)
            data.availability = self._extract_text(soup, ".availability-status")
            data.rating = self._extract_rating(soup)
            data.review_count = self._extract_review_count(soup)
            data.parsed_at = time.strftime("%Y-%m-%dT%H:%M:%SZ", time.gmtime())
        except Exception as e:
            logger.error(f"Parse error for {url}: {e}")
        return data
    def _extract_text(self, soup, selector: str) -> Optional[str]:
        el = soup.select_one(selector)
        return el.get_text(strip=True) if el else None
    def _extract_price(self, soup) -> Optional[float]:
        el = soup.select_one("[data-price], .price, .product-price")
        if not el:
            return None
        price_text = el.get("data-price") or el.get_text(strip=True)
        # Remove currency symbols and parse
        cleaned = "".join(c for c in price_text if c.isdigit() or c == ".")
        return float(cleaned) if cleaned else None
    def _extract_currency(self, soup) -> Optional[str]:
        el = soup.select_one("[data-currency], .currency")
        return el.get("data-currency") or el.get_text(strip=True) if el else None
    def _extract_rating(self, soup) -> Optional[float]:
        el = soup.select_one("[data-rating], .rating-value")
        if el:
            val = el.get("data-rating") or el.get_text(strip=True)
            try:
                return float(val)
            except ValueError:
                return None
        return None
    def _extract_review_count(self, soup) -> Optional[int]:
        el = soup.select_one(".review-count, [data-reviews]")
        if el:
            text = el.get("data-reviews") or el.get_text(strip=True)
            digits = "".join(c for c in text if c.isdigit())
            return int(digits) if digits else None
        return None
# Usage
parser = ProductParser()
for result in results:
    if result["success"]:
        product = parser.parse(result["url"], result["body"])
        print(f"{product.title}: ${product.price}")

Componente 5: Armazenamento

Persist analisou dados com versão e deduplicação. Use upserts para lidar com recawls graciosamente.

import psycopg2
from psycopg2.extras import execute_values
from datetime import datetime
class DataStore:
    """Persists scraped data with upsert and versioning."""
    def __init__(self, dsn: str):
        self.conn = psycopg2.connect(dsn)
        self._ensure_tables()
    def _ensure_tables(self):
        with self.conn.cursor() as cur:
            cur.execute("""
                CREATE TABLE IF NOT EXISTS products (
                    url TEXT PRIMARY KEY,
                    title TEXT,
                    price NUMERIC(10,2),
                    currency VARCHAR(3),
                    availability TEXT,
                    rating NUMERIC(3,2),
                    review_count INTEGER,
                    first_seen_at TIMESTAMPTZ DEFAULT NOW(),
                    last_updated_at TIMESTAMPTZ DEFAULT NOW()
                );
                CREATE TABLE IF NOT EXISTS price_history (
                    id SERIAL PRIMARY KEY,
                    url TEXT REFERENCES products(url),
                    price NUMERIC(10,2),
                    recorded_at TIMESTAMPTZ DEFAULT NOW()
                );
            """)
            self.conn.commit()
    def upsert_products(self, products: list[ProductData]):
        """Insert or update products, recording price changes."""
        with self.conn.cursor() as cur:
            for product in products:
                if product.price is None:
                    continue
                # Check if price changed
                cur.execute(
                    "SELECT price FROM products WHERE url = %s",
                    (product.url,)
                )
                row = cur.fetchone()
                # Upsert product
                cur.execute("""
                    INSERT INTO products (url, title, price, currency, availability,
                                          rating, review_count, last_updated_at)
                    VALUES (%s, %s, %s, %s, %s, %s, %s, NOW())
                    ON CONFLICT (url) DO UPDATE SET
                        title = EXCLUDED.title,
                        price = EXCLUDED.price,
                        currency = EXCLUDED.currency,
                        availability = EXCLUDED.availability,
                        rating = EXCLUDED.rating,
                        review_count = EXCLUDED.review_count,
                        last_updated_at = NOW()
                """, (
                    product.url, product.title, product.price,
                    product.currency, product.availability,
                    product.rating, product.review_count,
                ))
                # Record price history if changed
                if row is None or float(row[0]) != product.price:
                    cur.execute(
                        "INSERT INTO price_history (url, price) VALUES (%s, %s)",
                        (product.url, product.price)
                    )
            self.conn.commit()
    @property
    def product_count(self) -> int:
        with self.conn.cursor() as cur:
            cur.execute("SELECT COUNT(*) FROM products")
            return cur.fetchone()[0]
# Usage
store = DataStore("postgresql://user:pass@localhost:5432/scraper")
store.upsert_products(parsed_products)
print(f"Total products: {store.product_count}")

Componente 6: Monitorização

Amarre todos os componentes com monitoramento centralizado. Para padrões detalhados de monitoramento proxy-específico, consulte Monitoramento do Desempenho do Proxy guia.

import time
import json
import logging
from datetime import datetime
class PipelineMonitor:
    """Monitors the entire scraping pipeline."""
    def __init__(self):
        self.logger = logging.getLogger("pipeline")
        self.stage_times = {}
        self.stage_counts = {}
    def start_stage(self, stage: str):
        self.stage_times[stage] = time.time()
    def end_stage(self, stage: str, item_count: int = 0):
        elapsed = time.time() - self.stage_times.get(stage, time.time())
        self.stage_counts[stage] = item_count
        self.logger.info(json.dumps({
            "timestamp": datetime.utcnow().isoformat(),
            "stage": stage,
            "duration_seconds": round(elapsed, 2),
            "items_processed": item_count,
            "items_per_second": round(item_count / elapsed, 1) if elapsed > 0 else 0,
        }))
    def report(self) -> dict:
        return {
            "stages": {
                stage: {
                    "items": self.stage_counts.get(stage, 0),
                }
                for stage in self.stage_counts
            },
            "timestamp": datetime.utcnow().isoformat(),
        }
# Usage within the full pipeline
monitor = PipelineMonitor()
# Stage 1: Schedule
monitor.start_stage("schedule")
urls = scheduler.dequeue(batch_size=500)
monitor.end_stage("schedule", len(urls))
# Stage 2: Crawl
monitor.start_stage("crawl")
results = asyncio.run(crawler.crawl([u["url"] for u in urls]))
monitor.end_stage("crawl", len(results))
# Stage 3: Parse
monitor.start_stage("parse")
products = [parser.parse(r["url"], r["body"]) for r in results if r["success"]]
monitor.end_stage("parse", len(products))
# Stage 4: Store
monitor.start_stage("store")
store.upsert_products(products)
monitor.end_stage("store", len(products))
print(json.dumps(monitor.report(), indent=2))

Recompondo tudo

Aqui está o oleoduto completo que conecta todos os seis componentes em um único sistema de raspagem executável.

import asyncio
import logging
logging.basicConfig(level=logging.INFO)
async def run_pipeline():
    # Initialize components
    scheduler = CrawlScheduler()
    crawler = CrawlerPool(concurrency=30, max_retries=3)
    parser = ProductParser()
    store = DataStore("postgresql://user:pass@localhost:5432/scraper")
    monitor = PipelineMonitor()
    # Schedule crawls
    scheduler.add_schedule(
        name="daily_products",
        urls=[f"https://example.com/product/{i}" for i in range(1, 501)],
        interval_hours=24,
        priority=8,
    )
    # Main loop
    while True:
        # 1. Check schedules and enqueue URLs
        monitor.start_stage("schedule")
        scheduler.tick()
        batch = scheduler.dequeue(batch_size=100)
        monitor.end_stage("schedule", len(batch))
        if not batch:
            await asyncio.sleep(60)
            continue
        # 2. Crawl
        monitor.start_stage("crawl")
        urls = [item["url"] for item in batch]
        results = await crawler.crawl(urls, country="us")
        successful = [r for r in results if r.get("success")]
        monitor.end_stage("crawl", len(successful))
        # 3. Parse
        monitor.start_stage("parse")
        products = []
        for result in successful:
            try:
                product = parser.parse(result["url"], result["body"])
                products.append(product)
            except Exception as e:
                logging.error(f"Parse error: {e}")
        monitor.end_stage("parse", len(products))
        # 4. Store
        monitor.start_stage("store")
        store.upsert_products(products)
        monitor.end_stage("store", len(products))
        # 5. Report
        logging.info(f"Pipeline: {monitor.report()}")
        logging.info(f"Crawler stats: {crawler.stats}")
        # Wait before next batch
        await asyncio.sleep(5)
asyncio.run(run_pipeline())

Padrões de implantação da produção

Escala Horizontal

Escale rastreadores independentemente de agendadores e analisadores. Execute várias instâncias de rastreamento consumindo da mesma fila do Redis.

Recuperação de Erros

• Queda do crawler: URLs permanecem na fila Redis. O novo rastreador apanha-os automaticamente.
• Falhas no proxy: A camada de middleware tenta novamente com IPs frescos. Falhas mantidas acionam alertas.
• Falhas no analisador: O HTML bruto é armazenado em uma fila de letras mortas para inspeção manual e atualizações do analisador.
• Falhas na base de dados: Parsed buffers de dados em memória / disco com registro de gravação-ahead até que o DB recupera.

Verificação da Qualidade dos Dados

class DataQualityChecker:
    """Validates parsed data before storage."""
    def check(self, product: ProductData) -> list[str]:
        issues = []
        if not product.title:
            issues.append("missing_title")
        if product.price is not None and product.price <= 0:
            issues.append("invalid_price")
        if product.price is not None and product.price > 100000:
            issues.append("suspicious_price")
        if product.rating is not None and (product.rating < 0 or product.rating > 5):
            issues.append("invalid_rating")
        return issues
    def filter_valid(self, products: list[ProductData]) -> list[ProductData]:
        valid = []
        for product in products:
            issues = self.check(product)
            if issues:
                logger.warning(f"Data quality issues for {product.url}: {issues}")
            else:
                valid.append(product)
        return valid
# Integrate into pipeline
checker = DataQualityChecker()
valid_products = checker.filter_valid(products)
store.upsert_products(valid_products)

A melhor arquitetura de raspagem é uma que você pode raciocinar sobre. Cada componente deve responder a três perguntas: O que faz? Como é que falha? Como se recupera?

Para o componente da camada proxy, ver Construindo uma Camada de Ferramentas do Proxy. Para otimizar o rendimento do rastreador, leia Scaling Proxy Solicitações com Controle de Concorrencia. Para rastreamento baseado em navegador, ver Proxies rotativas com dramaturgo. Para estratégias antidetecção, explorar como raspar sem ficar bloqueado.

Começar com Python SDK, Nó SDK, ou Ir SDK para integração de proxy. Explorar Preço do ProxyHat e documentação para alimentar a sua arquitectura de raspagem.

Perguntas Frequentes
