Diseñar una arquitectura de scraping fiable

Más allá de los scripts: ¿Por qué asuntos de arquitectura

Un rascador de un solo fichero funciona bien para cien páginas. Pero cuando usted necesita recoger millones de puntos de datos en docenas de sitios de destino en un horario recurrente, usted necesita un sistema — no un script. Una arquitectura fiable de raspado separa las preocupaciones en componentes independientes que pueden ser escalados, monitoreados y recuperados independientemente.

Esta guía recorre el diseño de un sistema de desguace de la producción, desde la programación URL a través de la gestión proxy hasta el almacenamiento de datos. Cada componente se ilustra con el código y se conecta al Infraestructura proxyHat.

Un raspador bien diseñado trata la recopilación de datos como un problema de ingeniería, no un problema de piratería. Cada componente tiene una sola responsabilidad, interfaces claras y comportamiento observable.

Resumen de la arquitectura del sistema

Un sistema de raspado de producción consta de seis componentes básicos:

┌─────────────┐     ┌──────────────┐     ┌─────────────────┐
│  Scheduler   │────▶│  URL Queue   │────▶│  Crawler Pool   │
│  (cron/API)  │     │  (Redis)     │     │  (workers)      │
└─────────────┘     └──────────────┘     └────────┬────────┘
                                                   │
                                          ┌────────▼────────┐
                                          │  Proxy Layer     │
                                          │  (ProxyHat)      │
                                          └────────┬────────┘
                                                   │
                                          ┌────────▼────────┐
                                          │  Parser          │
                                          │  (extract data)  │
                                          └────────┬────────┘
                                                   │
                    ┌──────────────┐      ┌────────▼────────┐
                    │  Monitoring  │◀─────│  Storage         │
                    │  (metrics)   │      │  (DB / files)    │
                    └──────────────┘      └─────────────────┘

Componente 1: Programador

El programador decide qué URL arrastrar y cuándo. Gestiona la frecuencia de rastreo, los niveles prioritarios y asegura que ninguna URL se raspa con más frecuencia de lo necesario.

import redis
import json
import time
from datetime import datetime, timedelta
class CrawlScheduler:
    """Manages crawl schedules and feeds URLs to the queue."""
    def __init__(self, redis_url: str = "redis://localhost:6379"):
        self.redis = redis.from_url(redis_url)
        self.queue_key = "scraper:url_queue"
        self.schedule_key = "scraper:schedules"
        self.seen_key = "scraper:seen_urls"
    def add_schedule(self, name: str, urls: list[str], interval_hours: int, priority: int = 5):
        """Register a recurring crawl job."""
        self.redis.hset(self.schedule_key, name, json.dumps({
            "urls": urls,
            "interval_hours": interval_hours,
            "priority": priority,
            "last_run": None,
        }))
    def tick(self):
        """Check all schedules and enqueue URLs that are due."""
        schedules = self.redis.hgetall(self.schedule_key)
        enqueued = 0
        for name, data in schedules.items():
            schedule = json.loads(data)
            last_run = schedule.get("last_run")
            interval = timedelta(hours=schedule["interval_hours"])
            if last_run and datetime.fromisoformat(last_run) + interval > datetime.utcnow():
                continue
            for url in schedule["urls"]:
                self.enqueue(url, priority=schedule["priority"])
                enqueued += 1
            schedule["last_run"] = datetime.utcnow().isoformat()
            self.redis.hset(self.schedule_key, name, json.dumps(schedule))
        return enqueued
    def enqueue(self, url: str, priority: int = 5):
        """Add a URL to the crawl queue with deduplication."""
        # Skip if recently seen (within 1 hour)
        if self.redis.sismember(self.seen_key, url):
            return False
        self.redis.zadd(self.queue_key, {
            json.dumps({"url": url, "enqueued_at": time.time()}): priority
        })
        self.redis.sadd(self.seen_key, url)
        self.redis.expire(self.seen_key, 3600)  # 1-hour dedup window
        return True
    def dequeue(self, batch_size: int = 10) -> list[dict]:
        """Pull the highest-priority URLs from the queue."""
        items = self.redis.zpopmax(self.queue_key, batch_size)
        return [json.loads(item) for item, score in items]
    @property
    def queue_size(self) -> int:
        return self.redis.zcard(self.queue_key)
# Usage
scheduler = CrawlScheduler()
scheduler.add_schedule(
    name="product_prices",
    urls=[f"https://example.com/product/{i}" for i in range(1, 1001)],
    interval_hours=6,
    priority=8,
)
scheduler.add_schedule(
    name="competitor_pages",
    urls=["https://competitor.com/pricing", "https://competitor.com/features"],
    interval_hours=24,
    priority=5,
)
# Run every minute via cron
enqueued = scheduler.tick()
print(f"Enqueued {enqueued} URLs, queue size: {scheduler.queue_size}")

Componente 2: URL Queue

La cola se descompone de arrastrarse. Proporciona orden de prioridad, retropresión y persistencia, por lo que no se pierden URLs si se bloquea un rastreador.

// Node.js queue with Bull
const Queue = require('bull');
const crawlQueue = new Queue('crawl', 'redis://localhost:6379', {
  defaultJobOptions: {
    attempts: 3,
    backoff: { type: 'exponential', delay: 2000 },
    removeOnComplete: 100,
    removeOnFail: 500,
  },
});
// Add URLs with priority (lower number = higher priority)
async function enqueueUrls(urls, priority = 5) {
  const jobs = urls.map(url =>
    crawlQueue.add(
      { url, enqueuedAt: Date.now() },
      { priority, jobId: url } // jobId for deduplication
    )
  );
  await Promise.all(jobs);
  console.log(`Enqueued ${urls.length} URLs`);
}
// Worker processes URLs
crawlQueue.process(10, async (job) => {
  const { url } = job.data;
  // Crawl logic here (see Crawler Pool below)
  return { url, status: 'completed' };
});
crawlQueue.on('failed', (job, err) => {
  console.error(`Job ${job.id} failed: ${err.message}`);
});

Componente 3: Grupo Crawler

Las páginas de la piscina de rastreadores coinciden capa de middleware proxy. límites de concurrencia, maneja retries, y pasa respuestas crudas al analizador.

import asyncio
import aiohttp
import uuid
import time
from typing import Optional
class CrawlerPool:
    """Concurrent crawler with proxy rotation and retry logic."""
    def __init__(
        self,
        concurrency: int = 30,
        max_retries: int = 3,
        timeout: int = 30,
    ):
        self.concurrency = concurrency
        self.max_retries = max_retries
        self.timeout = aiohttp.ClientTimeout(total=timeout)
        self.semaphore = asyncio.Semaphore(concurrency)
        self.stats = {"success": 0, "failed": 0, "retries": 0}
    def _get_proxy(self, country: Optional[str] = None) -> str:
        session_id = uuid.uuid4().hex[:8]
        username = f"USERNAME-session-{session_id}"
        if country:
            username += f"-country-{country}"
        return f"http://{username}:PASSWORD@gate.proxyhat.com:8080"
    async def fetch(
        self,
        session: aiohttp.ClientSession,
        url: str,
        country: Optional[str] = None,
    ) -> dict:
        async with self.semaphore:
            for attempt in range(self.max_retries + 1):
                proxy = self._get_proxy(country)
                start = time.time()
                try:
                    async with session.get(
                        url, proxy=proxy, timeout=self.timeout,
                        headers={
                            "User-Agent": "Mozilla/5.0 (Windows NT 10.0; Win64; x64) "
                                          "AppleWebKit/537.36 Chrome/131.0.0.0 Safari/537.36",
                            "Accept": "text/html,application/xhtml+xml,*/*;q=0.8",
                        },
                    ) as response:
                        body = await response.text()
                        latency = time.time() - start
                        if response.status in (403, 429, 503) and attempt < self.max_retries:
                            self.stats["retries"] += 1
                            await asyncio.sleep(2 ** attempt)
                            continue
                        if response.status < 400:
                            self.stats["success"] += 1
                        else:
                            self.stats["failed"] += 1
                        return {
                            "url": url,
                            "status": response.status,
                            "body": body,
                            "latency": latency,
                            "success": response.status < 400,
                        }
                except Exception as e:
                    if attempt < self.max_retries:
                        self.stats["retries"] += 1
                        await asyncio.sleep(2 ** attempt)
                        continue
                    self.stats["failed"] += 1
                    return {
                        "url": url,
                        "error": str(e),
                        "latency": time.time() - start,
                        "success": False,
                    }
    async def crawl(self, urls: list[str], country: Optional[str] = None) -> list[dict]:
        async with aiohttp.ClientSession() as session:
            tasks = [self.fetch(session, url, country) for url in urls]
            return await asyncio.gather(*tasks)
# Usage
crawler = CrawlerPool(concurrency=30, max_retries=3)
urls = [f"https://example.com/product/{i}" for i in range(500)]
results = asyncio.run(crawler.crawl(urls, country="us"))
print(f"Success: {crawler.stats['success']}, Failed: {crawler.stats['failed']}")

Componente 4: Parser

El analizador transforma HTML crudo en datos estructurados. Mantener la lógica de parsing separada de la arrastre — esto hace que sea testable, reutilizable y fácil de actualizar cuando los sitios de destino cambian.

from dataclasses import dataclass
from typing import Optional
from bs4 import BeautifulSoup
import json
@dataclass
class ProductData:
    url: str
    title: Optional[str] = None
    price: Optional[float] = None
    currency: Optional[str] = None
    availability: Optional[str] = None
    rating: Optional[float] = None
    review_count: Optional[int] = None
    parsed_at: Optional[str] = None
class ProductParser:
    """Extracts structured product data from HTML."""
    def parse(self, url: str, html: str) -> ProductData:
        soup = BeautifulSoup(html, "html.parser")
        data = ProductData(url=url)
        try:
            data.title = self._extract_text(soup, "h1.product-title")
            data.price = self._extract_price(soup)
            data.currency = self._extract_currency(soup)
            data.availability = self._extract_text(soup, ".availability-status")
            data.rating = self._extract_rating(soup)
            data.review_count = self._extract_review_count(soup)
            data.parsed_at = time.strftime("%Y-%m-%dT%H:%M:%SZ", time.gmtime())
        except Exception as e:
            logger.error(f"Parse error for {url}: {e}")
        return data
    def _extract_text(self, soup, selector: str) -> Optional[str]:
        el = soup.select_one(selector)
        return el.get_text(strip=True) if el else None
    def _extract_price(self, soup) -> Optional[float]:
        el = soup.select_one("[data-price], .price, .product-price")
        if not el:
            return None
        price_text = el.get("data-price") or el.get_text(strip=True)
        # Remove currency symbols and parse
        cleaned = "".join(c for c in price_text if c.isdigit() or c == ".")
        return float(cleaned) if cleaned else None
    def _extract_currency(self, soup) -> Optional[str]:
        el = soup.select_one("[data-currency], .currency")
        return el.get("data-currency") or el.get_text(strip=True) if el else None
    def _extract_rating(self, soup) -> Optional[float]:
        el = soup.select_one("[data-rating], .rating-value")
        if el:
            val = el.get("data-rating") or el.get_text(strip=True)
            try:
                return float(val)
            except ValueError:
                return None
        return None
    def _extract_review_count(self, soup) -> Optional[int]:
        el = soup.select_one(".review-count, [data-reviews]")
        if el:
            text = el.get("data-reviews") or el.get_text(strip=True)
            digits = "".join(c for c in text if c.isdigit())
            return int(digits) if digits else None
        return None
# Usage
parser = ProductParser()
for result in results:
    if result["success"]:
        product = parser.parse(result["url"], result["body"])
        print(f"{product.title}: ${product.price}")

Componente 5: Almacenamiento

Persiste datos analizados con versión y deduplicación. Usen refuerzos para manejar re-crawls con gracia.

import psycopg2
from psycopg2.extras import execute_values
from datetime import datetime
class DataStore:
    """Persists scraped data with upsert and versioning."""
    def __init__(self, dsn: str):
        self.conn = psycopg2.connect(dsn)
        self._ensure_tables()
    def _ensure_tables(self):
        with self.conn.cursor() as cur:
            cur.execute("""
                CREATE TABLE IF NOT EXISTS products (
                    url TEXT PRIMARY KEY,
                    title TEXT,
                    price NUMERIC(10,2),
                    currency VARCHAR(3),
                    availability TEXT,
                    rating NUMERIC(3,2),
                    review_count INTEGER,
                    first_seen_at TIMESTAMPTZ DEFAULT NOW(),
                    last_updated_at TIMESTAMPTZ DEFAULT NOW()
                );
                CREATE TABLE IF NOT EXISTS price_history (
                    id SERIAL PRIMARY KEY,
                    url TEXT REFERENCES products(url),
                    price NUMERIC(10,2),
                    recorded_at TIMESTAMPTZ DEFAULT NOW()
                );
            """)
            self.conn.commit()
    def upsert_products(self, products: list[ProductData]):
        """Insert or update products, recording price changes."""
        with self.conn.cursor() as cur:
            for product in products:
                if product.price is None:
                    continue
                # Check if price changed
                cur.execute(
                    "SELECT price FROM products WHERE url = %s",
                    (product.url,)
                )
                row = cur.fetchone()
                # Upsert product
                cur.execute("""
                    INSERT INTO products (url, title, price, currency, availability,
                                          rating, review_count, last_updated_at)
                    VALUES (%s, %s, %s, %s, %s, %s, %s, NOW())
                    ON CONFLICT (url) DO UPDATE SET
                        title = EXCLUDED.title,
                        price = EXCLUDED.price,
                        currency = EXCLUDED.currency,
                        availability = EXCLUDED.availability,
                        rating = EXCLUDED.rating,
                        review_count = EXCLUDED.review_count,
                        last_updated_at = NOW()
                """, (
                    product.url, product.title, product.price,
                    product.currency, product.availability,
                    product.rating, product.review_count,
                ))
                # Record price history if changed
                if row is None or float(row[0]) != product.price:
                    cur.execute(
                        "INSERT INTO price_history (url, price) VALUES (%s, %s)",
                        (product.url, product.price)
                    )
            self.conn.commit()
    @property
    def product_count(self) -> int:
        with self.conn.cursor() as cur:
            cur.execute("SELECT COUNT(*) FROM products")
            return cur.fetchone()[0]
# Usage
store = DataStore("postgresql://user:pass@localhost:5432/scraper")
store.upsert_products(parsed_products)
print(f"Total products: {store.product_count}")

Componente 6: Vigilancia

Tie all components together with centralized monitoring. Para patrones de monitoreo específicos proxy detallados, vea nuestra Supervisión del rendimiento indirecto guía.

import time
import json
import logging
from datetime import datetime
class PipelineMonitor:
    """Monitors the entire scraping pipeline."""
    def __init__(self):
        self.logger = logging.getLogger("pipeline")
        self.stage_times = {}
        self.stage_counts = {}
    def start_stage(self, stage: str):
        self.stage_times[stage] = time.time()
    def end_stage(self, stage: str, item_count: int = 0):
        elapsed = time.time() - self.stage_times.get(stage, time.time())
        self.stage_counts[stage] = item_count
        self.logger.info(json.dumps({
            "timestamp": datetime.utcnow().isoformat(),
            "stage": stage,
            "duration_seconds": round(elapsed, 2),
            "items_processed": item_count,
            "items_per_second": round(item_count / elapsed, 1) if elapsed > 0 else 0,
        }))
    def report(self) -> dict:
        return {
            "stages": {
                stage: {
                    "items": self.stage_counts.get(stage, 0),
                }
                for stage in self.stage_counts
            },
            "timestamp": datetime.utcnow().isoformat(),
        }
# Usage within the full pipeline
monitor = PipelineMonitor()
# Stage 1: Schedule
monitor.start_stage("schedule")
urls = scheduler.dequeue(batch_size=500)
monitor.end_stage("schedule", len(urls))
# Stage 2: Crawl
monitor.start_stage("crawl")
results = asyncio.run(crawler.crawl([u["url"] for u in urls]))
monitor.end_stage("crawl", len(results))
# Stage 3: Parse
monitor.start_stage("parse")
products = [parser.parse(r["url"], r["body"]) for r in results if r["success"]]
monitor.end_stage("parse", len(products))
# Stage 4: Store
monitor.start_stage("store")
store.upsert_products(products)
monitor.end_stage("store", len(products))
print(json.dumps(monitor.report(), indent=2))

Poner todo juntos

Aquí está el gasoducto completo que conecta los seis componentes en un único sistema de raspado ejecutable.

import asyncio
import logging
logging.basicConfig(level=logging.INFO)
async def run_pipeline():
    # Initialize components
    scheduler = CrawlScheduler()
    crawler = CrawlerPool(concurrency=30, max_retries=3)
    parser = ProductParser()
    store = DataStore("postgresql://user:pass@localhost:5432/scraper")
    monitor = PipelineMonitor()
    # Schedule crawls
    scheduler.add_schedule(
        name="daily_products",
        urls=[f"https://example.com/product/{i}" for i in range(1, 501)],
        interval_hours=24,
        priority=8,
    )
    # Main loop
    while True:
        # 1. Check schedules and enqueue URLs
        monitor.start_stage("schedule")
        scheduler.tick()
        batch = scheduler.dequeue(batch_size=100)
        monitor.end_stage("schedule", len(batch))
        if not batch:
            await asyncio.sleep(60)
            continue
        # 2. Crawl
        monitor.start_stage("crawl")
        urls = [item["url"] for item in batch]
        results = await crawler.crawl(urls, country="us")
        successful = [r for r in results if r.get("success")]
        monitor.end_stage("crawl", len(successful))
        # 3. Parse
        monitor.start_stage("parse")
        products = []
        for result in successful:
            try:
                product = parser.parse(result["url"], result["body"])
                products.append(product)
            except Exception as e:
                logging.error(f"Parse error: {e}")
        monitor.end_stage("parse", len(products))
        # 4. Store
        monitor.start_stage("store")
        store.upsert_products(products)
        monitor.end_stage("store", len(products))
        # 5. Report
        logging.info(f"Pipeline: {monitor.report()}")
        logging.info(f"Crawler stats: {crawler.stats}")
        # Wait before next batch
        await asyncio.sleep(5)
asyncio.run(run_pipeline())

Patrones de Despliegue de Producción

Escalada horizontal

Rastreadores de escala independientemente de los cronogramadores y persianas. Ejecute múltiples instancias de rastreador que consumen de la misma cola de Redis.

Recuperación de errores

• Crawler: Las URL permanecen en la cola Redis. Los nuevos rastreadores los recogen automáticamente.
• Fallos proxy: El capa de middleware retries con IPs frescas. Los fallos sostenidos desencadenan alertas.
• Fallos del parser: El HTML crudo se almacena en una cola de letras muertas para la inspección manual y actualizaciones de parser.
• Fallos de base: Búferes de datos pareados en memoria/disk con registro de escritura-ahead hasta que el DB se recupera.

Controles de calidad de datos

class DataQualityChecker:
    """Validates parsed data before storage."""
    def check(self, product: ProductData) -> list[str]:
        issues = []
        if not product.title:
            issues.append("missing_title")
        if product.price is not None and product.price <= 0:
            issues.append("invalid_price")
        if product.price is not None and product.price > 100000:
            issues.append("suspicious_price")
        if product.rating is not None and (product.rating < 0 or product.rating > 5):
            issues.append("invalid_rating")
        return issues
    def filter_valid(self, products: list[ProductData]) -> list[ProductData]:
        valid = []
        for product in products:
            issues = self.check(product)
            if issues:
                logger.warning(f"Data quality issues for {product.url}: {issues}")
            else:
                valid.append(product)
        return valid
# Integrate into pipeline
checker = DataQualityChecker()
valid_products = checker.filter_valid(products)
store.upsert_products(valid_products)

La mejor arquitectura de raspado es la que puedes razonar. Cada componente debe responder a tres preguntas: ¿Qué hace? ¿Cómo falla? ¿Cómo se recupera?

Para el componente de capa proxy, vea Construyendo una capa de Middleware Proxy. Para optimizar el rendimiento de los rastreadores, leer Scaling Proxy Solicita con Control de Concurrencia. Para gatear basado en el navegador, ver Proxies giratorios con Playwright. Para estrategias antidetección, explore cómo raspar sin ser bloqueado.

Empieza con Python SDK, Nodo SDKo Go SDK para la integración proxy. Explorar ProxyHat pricing y documentación para potenciar tu arquitectura de raspado.

Preguntas frecuentes
